卡箍连接电磁流量计

ATLD Tri-clamp Electromagnetic Flow Meter

Measuring medium: Conductive liquid
Diameter range: DN3mm~DN3000mm
Accuracy: ± 0.5% of the indicated value, optional ± 0.3% or ± 0.2%
Measuring range (Flow rate): 0.01m/s~15m/s
Electromagnetic flow meter is one of the most popular flow meters. clamp-on electromagnetic flow meter has been used for more than 50 years worldwide. It is widely used for all conductive liquids in every industry, such as water, acid, alkali, milk, slurry etc.
Introduction
Electromagnetic flow meter is one of the most popular flow meters. clamp-on electromagnetic flow meter has been used for more than 50 years worldwide. It is widely used for all conductive liquids in every industry, such as water, acid, alkali, milk, slurry etc.

The main advantages of using electromagnetic flow meter is that it is with no moving parts, no pressure loss and require very less maintenance.
clamp-on magnetic flow meter can be made large size range from DN3-DN3000mm and with bi-directional flow measurement. Aister's electromagnetic flow meters are with built-in self-diagnosis function and support data record / bluetooth function and various kinds of output signals.

Compared with other liquid type flow meter, the limitations of magnetic flow meter is that it can only be used for conductive liquid.Regarding non or low conductive liquid such as petroleum products, organic solvents can not be used. Electromagnetic flow meter will be affected if there's strong magnetic filed in the surrounding environment.
Features


01
1.Best accuracy:±0.5%,±0.2%;
02
2.Excellent measuring accuracy to low velocity, could measure double direction flows;
03
3.Buried sensor(IP68), no need to build measure well while installation;
04
4.Precision coil winding technology, makes magnetic field more uniform;
05
5.Build-in reference electrodes, no need to connect ground ring;
06
6.Dual frequency excitation, and stable zero point;
07
7.Self-diagnostic function, and intelligent operation;
Specifications
Performance Technical parameter
Size DN3-DN3000mm
Nominal Pressure 0.6-1.6Mpa(2.5Mpa/4.0Mpa/6.4Mpa...Max 42Mpa)
Accuracy +/-0.5%(Standard)     +/-0.3% or +/-0.2%(Optional)
Liner PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode SUS316L, Hastelloy B, Hastelloy C       Titanium, Tantalum, Platinium-iridium
Structure Type Integral type, remote type, submersible type, ex-proof type
Medium Temperature -20~+60 degC(Integral type)
Remote type ( Neoprene ,Hard Rubber ,Polyurethane ,EPDM) -10~+80degC
Remote type(PTFE/PFA/FEP) -10~+160degC
Ambient Temperature -20~+60deg C
Ambient Humidity 5-100%RH(relative humidity)
Measuring Range Max 15m/s
Conductivity >5us/cm
Protection Class IP65(Standard); IP68(Optional for remote type)
Process Connection Flange (Standard), Wafer, Thread, Tri-clamp etc (Optional)
Output Signal 4-20mA/Pulse
Communication RS485(Standard), HART(Optional),GPRS/GSM (Optional)
Power Supply AC220V (can be used for AC85-250V)
DC24V (can be used for DC20-36V)
DC12V (optional), Battery Powered 3.6V (optional)
Power Consumption <20W
Alarm Upper Limit Alarm / Lower Limit Alarm
Self-diagnosis Empty Pipe Alarm, Exciting Alarm
Explosion Proof ATEX
Model Selection
01 Caliber
02 Nominal Pressure
03 Connection Mode
04 Liner Material
05 Electrode Material
06 Structure Type
07 Power
08 Output communication
09 Converter Figure
Installation

Installation requirements

In order to let you can correct measuring, please be pay attention to the following requirements when choosing the line position
(1)the sensor not only installed in the straight pipe, but also can be installation the in level or tilted pipe, but the required of the center of two electrode attachment on the horizontal state
(2) the medium in the installation position should be full pipe flow, avoid not full pipe and gas attached to the electrode.
 (3) For liquid-solid two-phase flow, it better choose the perpendicular installation, it make the liner material of the sensor attrition uniform, and prolong working life.
(4) when the flow meter installation position with not full medium, it can raise the end pipeline of the flowmeter, and make its full tube, forbidden in peak and outlet pipe installation flowmeter
(5) Modify piping installation method: when the medium velocity out of requires, it should choose a small caliber flow meter, and should use different caliber taper pipe or modify the sections of pipe, make its same caliber with sensor, but before and after straight pipe section at least requirement the before straight pipe section ≥10 DN, after straight pipe section≥5 DN (DN for pipe diameter)
(6) Before and after straight pipe section for the flowmeter ,before pipe section ≥10 DN, after pipe section≥5 DN

The instrument connection
If choose the signal of remote version connected, the cable must be use the customized special cables. And the cable shorter the better
Excitation cable can choose Yz medium rubber cable ,and the length same as signal cable
Signal cable must be strictly separate with others power supply,and can not laying in the same pipe inside.
Signal cable and excitation cable should choose the shorter as soon as possible,and it can't coil together with the redundant cables,it should cut off the redundant cables,then rewelding the connector
when cable mediate sensor interface, in port place to make U, it will prevent the rain penetration to the sensor.
