What are the installation conditions of the vortex gas flowmeter

Vortex flowmeter is also known as Karman vortex flowmeter. It is a separation flowmeter made of the principle of natural oscillation of fluid. When a fluid flows at a sufficiently large velocity through an object perpendicular to the direction of the fluid, if the object is of appropriate size, it will produce a neatly aligned and reversed vortex train behind the object along two parallel lines.

As a very special medium, steam will show special phenomena and problems in the process of vortex flowmeter measurement. The key problem is that the vapor density value deviates too much from the design value, which brings significant measurement errors to the measurement results. At present, the density measuring instrument with mature technology has not been successfully applied, which brings certain difficulties to the steam flow measurement.

When choosing the right ammonia flow meter for you, several factors need to be considered to ensure the accuracy of the measurement results and the reliability of the equipment. Here’s a detailed buying guide:

Vortex flowmeter is mainly used for the flow measurement of industrial pipeline medium fluids, such as gas, liquid, vapor and other media. In addition to the characteristics of the aforementioned vortex flowmeter, it also has the following characteristics:

1. Vibration effect

Compressed air is generated by air compressor or high pressure fan. When these devices are in operation, they all have varying degrees of vibration, and sometimes the vibration is relatively strong, and this vibration is transmitted through the connecting pipe. When selecting and determining the position of the vortex flowmeter, this influencing factor should be fully considered. In various detection methods, the anti-vibration performance of the instrument is not the same due to different detection components. For the vortex street of the detection element, the vibration resistance can reach 0.5~1G. When determining the installation position of the vortex flowmeter, it should be as far away from the power equipment such as air compressors and fans as possible.

Precession vortex flowmeter without mechanical moving parts, small size, corrosion resistance, stable performance; It can directly display the working pressure, temperature, flow rate and gas volume under standard state of the medium; With the advantages of wide measuring range and small measuring error, the precession vortex flowmeter has been widely used in the production measurement of oil and gas Wells and the sales measurement of natural gas.

Vortex flowmeter can be widely used in large, medium and small kinds of pipeline water supply and drainage, industrial circulation, sewage treatment, oil and chemical reagents and compressed air, saturated and superheated steam, natural gas and various media flow measurement and can be used as a flow transmitter in automatic control system, long service life. Points of attention for vortex flowmeter installation:

Vortex flowmeter is a commonly used flow meter, the use of any instrument is inseparable from daily maintenance and maintenance, whether it is its own failure or interference by external factors, we calmly respond to the occurrence of failure.

Installation environment of vortex flowmeter:

Vortex flowmeter is a commonly used flow meter, the use of any instrument is inseparable from daily maintenance and maintenance, whether it is its own failure or interference by external factors, we calmly respond to the occurrence of failure.

Vortex flowmeter is a new flowmeter successfully developed on the basis of Karman vortex principle. Vortex flowmeter is suitable for measuring the mass flow and volume flow of superheated steam, saturated steam, compressed air, general gas, water and low corrosive liquid. How to ensure the accuracy of vortex flowmeter measurement during installation?

Vortex flow meters find diverse applications across industries where accurate measurement and monitoring of fluid flow are critical. One prominent use is in the oil and gas sector, where vortex flow meters are employed to measure the flow rates of various hydrocarbons. These meters excel in handling the challenges posed by the varying viscosities and temperatures of oil and gas, providing reliable measurements for custody transfer, production monitoring, and process optimization.

The structure of the vortex flowmeter is relatively simple, only the sensor and the display instrument are composed of two parts, and the measurement accuracy and stability are also relatively stable.

In the selection process of the vortex flow meter, in addition to the selection of a high-precision type in a comprehensive consideration of the demand, other accessories of the vortex flow meter are also very important, such as the selection of flow transmitters and the selection of compensatory pressure transmitters.

The vortex flowmeter is used in measuring coke oven gas, and the coke oven gas in some coke plants has been developed in the direction of civil gas. As a result, the problem of gas measurement becomes more and more prominent, and the demand for accuracy of gas measurement becomes higher and higher. However, there will be some problems in use, let’s talk about the causes and solutions of these problems:

Vortex flowmeter is a new type flowmeter for measuring fluid flow in closed pipeline according to Karman vortex principle. It is mainly used for the flow measurement of industrial pipeline medium fluids, such as gas, liquid, vapor and other media. It is characterized by small pressure loss, large range, high accuracy, and is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring volume flow under working conditions.

Vortex steam flowmeter is one of the main flowmeter products, widely used in petroleum, chemical industry, metallurgy, heating and other departments. Test and measure the flow of liquid, gas and steam.

Vortex flowmeter is widely used because of its wide range, small pressure loss, medium accuracy, linear output, no moving parts, high reliability, small maintenance, medium low price, and relatively high performance price characteristics.

1, pulse vortex flowmeter is a kind of high measurement accuracy, simple installation, small maintenance, a wide range of meters, is currently widely used in petrochemical, metallurgy, textile, urban construction, energy and other industries.

As industries continue to seek efficient and reliable flow measurement solutions, vortex flow meters stand out for their accuracy, adaptability, and durability. Their ability to provide real-time data and facilitate process optimization makes them indispensable tools for ensuring the efficient operation of various industrial processes where precise flow measurements are essential.

Measuring medium：Liquid, gas, saturated steam, superheated steam
Accuracy：Liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Working pressure：1.6MPa，2.5MPa，4.0MPa，6.4MPa
Medium temperature：Ordinary type -40 ~ 150℃
Medium temperature type -40 ~ 250℃
High temperature type -40 ~ 350℃
Output signal：Three-wire voltage pulse, low level 0 ~ 1V,
high level > 4V, duty cycle 50%;
Two-wire system standard current 4 ~ 20mA;
Three-wire system standard current 0 ~ 10mA
Working environment：-35℃～+60℃，Humidity ≤95%RH
Working power supply：DC12V；DC24V
Material：Carbon steel, stainless steel
Explosion-proof type：Intrinsically safe ExibIICT6

Vortex flowmeter is a velocity flowmeter, which measures the volume flow rate in the working state. If you choose the table according to the volume flow rate, the mass flow rate provided by the customer should be converted into the volume flow rate under the working state, and then determine the diameter of the selected instrument against the volume flow parameter.

Gas flowmeter is a general term for many measurable gas flows. Today, we mainly explain the installation conditions of vortex flowmeter.

Compressed air is generated by air compressor or high pressure fan. When these devices are in operation, they all have varying degrees of vibration, and sometimes the vibration is relatively strong, and this vibration is transmitted through the connecting pipe.

The method and requirements of temperature compensation will vary according to the specific application. In general, temperature compensation can be used in the following ways:

Whether the temperature and pressure compensation is required for steam measurement by vortex flowmeter mainly depends on the properties of the steam being measured and the requirements of measurement accuracy.

Vortex flowmeter common faults and solutions

The installation of the vortex flowmeter has different provisions, used to measure different measured media, different positions, then the installation method is not the same, the attention point is different, generally speaking, the vortex flowmeter has the following specified points:

Nominal diameter: DN15～DN300mm
Accuracy: liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Structure form: Integrated, split, temperature and pressure compensation
Applicable medium: liquid, gas, saturated steam, superheated steam

One of the notable advantages of vortex flow meters is their versatility, as they can be employed in a wide range of applications across different industries. They are particularly useful for measuring the flow of fluids with varying viscosities, making them suitable for applications in petrochemical, pharmaceutical, and water treatment industries. Additionally, vortex flow meters are known for their ability to handle both high and low-flow conditions with consistent accuracy, providing reliable measurements across a broad operational range.

Measuring medium：Liquid, gas, saturated steam, superheated steam
Accuracy：Liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Working pressure：1.6MPa，2.5MPa，4.0MPa，6.4MPa
Medium temperature：Ordinary type -40 ~ 150℃
Medium temperature type -40 ~ 250℃
High temperature type -40 ~ 350℃
Output signal：Three-wire voltage pulse, low level 0 ~ 1V,
high level > 4V, duty cycle 50%;
Two-wire system standard current 4 ~ 20mA;
Three-wire system standard current 0 ~ 10mA
Working environment：-35℃～+60℃，Humidity ≤95%RH
Working power supply：DC12V；DC24V
Material：Carbon steel, stainless steel
Explosion-proof type：Intrinsically safe ExibIICT6

Due to the compressibility of the gas, its flow measurement is more complex than that of the liquid, and the output signal of the vortex flowmeter is related to the gas density in addition to the input signal, and the density of the gas is a function of temperature and pressure (referred to as temperature and pressure).
