Wall Mounted Clamp Ultrasonic Flowmeter Wall Hanging Ultrasonic Flow Meter

Size: DN3-DN3000mm
Nominal Pressure: 0.6-1.6Mpa(2.5Mpa/4.0Mpa/6.4Mpa…Max 42Mpa)
Accuracy: +/-0.5%(Standard), 0.3% or 0.2% (Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Output Signal: 4-20mA/Pulse

Measuring medium: single sound conducting liquid medium
Measuring range: ± 0.03ft /s~ ± 40ft /s (± 0.01m /s~ ± 12m /s)
Accuracy class: ±1%
Pipe diameter range: 1″~48″(25mm~1200mm)
Handheld (portable) ultrasonic flowmeter with external clip-on sensing to measure liquid flow. The installation process is extremely simple, and the all-Chinese man-machine interface makes it easier to operate.

Intelligent precession vortex flowmeter is a new type of gas flow meter developed by our company. The flowmeter integrates the function of flow, temperature and pressure detection, and can automatically compensate the temperature, pressure and compression factor. It is an ideal instrument for gas measurement in petroleum, chemical industry, electric power, metallurgy and other industries.

The thermal gas mass flowmeter is an instrument that uses the principle of heat conduction to measure fluid flow. The instrument uses the constant temperature difference method to measure the gas flow accurately. It has the advantages of small size, high digitization, easy installation and accurate measurement. Today we are mainly to talk about the thermal gas mass flowmeter in the installation process need to pay attention to what are?

The electromagnetic flowmeter is constructed in such a way that it mainly consists of a number of key components that work together to measure the flow of a conductive liquid. The following is the main structure of the electromagnetic flowmeter and its functions:

Turbine flowmeter is a kind of speed instrument, which has the advantages of high precision, good repeatability, simple structure, high pressure resistance, wide measuring range, small size, light weight, small pressure loss, long life, simple operation, easy maintenance, etc., used to measure the volume flow and accumulation of low viscosity, no strong corrosion and clean liquid in closed pipelines. It can be widely used in petroleum, chemical industry, metallurgy, organic liquid, inorganic liquid, liquefied gas, urban gas pipe network, pharmaceutical, food, paper and other industries.

Thermal gas mass flowmeter has a wide range of applications in many fields, its high precision, rapid response and stability characteristics make it in a variety of gas flow measurement occasions can play an excellent performance, for the development of various industries to provide more reliable technical support.

1. Principle of thermal gas mass flowmeter

Thermal gas mass flowmeter The thermal distributed flowmeter uses the flow fluid to transfer heat to change the heat conduction distribution effect of measuring the temperature distribution of the tube wall. 2) King’s Law using the heat dissipation (cooling) effect. And because the structure of the detection element extends into the measuring tube, also known as immersion or intrusion type. Some instruments that are inserted from outside the tube into the process tube when in use are called plug-in.

Coriolis mass flowmeters are robust instruments, but like any measurement device, they can experience faults or issues. Here are some common faults with Coriolis mass flowmeters and their possible solutions:

One key advantage of electromagnetic flow meters is their versatility in handling various fluid types and conditions. Since they rely on the conductivity of the fluid rather than its physical properties, these meters are suitable for a wide range of applications, from clean water to corrosive chemicals. Additionally, they exhibit minimal pressure loss, making them an energy-efficient choice for flow measurement systems.

Nominal diameter: DN4-DN200mm
Accuracy: ±1%R、±0.5%R、±0.2%R (to be customized)
Instrument type: Field display type, pulse output type, 4-20mA output type, split remote display type
Applicable medium: No impurities, low viscosity, no strong corrosive liquid

In the energy sector, particularly in the oil and gas industry, ultrasonic flow meters are widely used to measure the flow rates of hydrocarbons in pipelines. These meters offer a non-intrusive solution for accurately monitoring oil and gas flows, ensuring precise measurement without the need for cutting into pipelines. The ability to operate in challenging environments, such as high-pressure pipelines, makes ultrasonic flow meters suitable for upstream and downstream applications, providing essential data for process control and optimization.

Electromagnetic flowmeters can achieve remote communication through various digital communication protocols. These protocols allow flowmeter data to be transmitted to remote monitoring systems, control rooms, or other devices for real-time monitoring, analysis, and control. Some common digital communication protocols used for remote communication with electromagnetic flowmeters include:

Electromagnetic flowmeters, commonly known as magmeters, are a sophisticated and versatile type of flow measurement device widely used in industrial applications. Unlike traditional mechanical flow meters, electromagnetic flowmeters operate on the principle of electromagnetic induction to provide highly accurate and reliable measurements of liquid flow. The technology behind these devices makes them suitable for a diverse range of industries where precise flow measurement is crucial for various processes.

Size: DN3-DN3000mm
Nominal Pressure: 0.6-1.6Mpa(2.5Mpa/4.0Mpa/6.4Mpa…Max 42Mpa)
Accuracy: +/-0.5%(Standard) +/-0.3% or +/-0.2%(Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode: SUS316L, Hastelloy B, Hastelloy C Titanium, Tantalum, Platinium-iridium
Structure Type: Integral type, remote type, submersible type, ex-proof type

The ability of electromagnetic flowmeters to provide real-time data on fluid flow rates is a key performance aspect. Industries benefit from the immediate and accurate insights into their processes, allowing for proactive monitoring and control. This feature is especially crucial in applications such as water distribution networks, where real-time data facilitates efficient resource management and timely responses to changes in flow conditions.

Measuring Range: Max 15m/s
Conductivity: >5us/cm
Protection Class: IP65(Standard); IP68(Optional for remote type)
Process Connection: Flange (Standard), Wafer, Thread, Tri-clamp etc (Optional)
Output Signal: 4-20mA/Pulse
Communication: RS485(Standard), HART(Optional),GPRS/GSM (Optional)
Power Supply: AC220V (can be used for AC85-250V)
DC24V (can be used for DC20-36V)
DC12V (optional), Battery Powered 3.6V (optional)
Power Consumption: <20W Alarm: Upper Limit Alarm / Lower Limit Alarm Self-diagnosis: Empty Pipe Alarm, Exciting Alarm Explosion Proof: ATEX

vortex flow meter is a specialized instrument designed for measuring the flow rate of liquids, gases, or steam in various industrial processes. It operates on the principle of the Von Kármán effect, where a bluff body (typically a shedder bar or a blunt object) is placed in the flow stream. As the fluid passes by the bluff body, vortices are formed alternately on either side, creating a pattern. The frequency of these vortices is directly proportional to the velocity of the flowing fluid, allowing the vortex flow meter to accurately determine the flow rate.

Measuring medium：Liquid, gas, saturated steam, superheated steam
Accuracy：Liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Working pressure：1.6MPa，2.5MPa，4.0MPa，6.4MPa
Medium temperature：Ordinary type -40 ~ 150℃
Medium temperature type -40 ~ 250℃
High temperature type -40 ~ 350℃
Output signal：Three-wire voltage pulse, low level 0 ~ 1V,
high level > 4V, duty cycle 50%;
Two-wire system standard current 4 ~ 20mA;
Three-wire system standard current 0 ~ 10mA
Working environment：-35℃～+60℃，Humidity ≤95%RH
Working power supply：DC12V；DC24V
Material：Carbon steel, stainless steel
Explosion-proof type：Intrinsically safe ExibIICT6

Intelligent precession vortex flowmeter is a new type of gas flow meter developed by our company. The flowmeter integrates the function of flow, temperature and pressure detection, and can automatically compensate the temperature, pressure and compression factor. It is an ideal instrument for gas measurement in petroleum, chemical industry, electric power, metallurgy and other industries.

Measuring medium: Conductive liquid
Diameter range: DN3mm～DN3000mm
Accuracy: ± 0.5% of the indicated value, optional ± 0.3% or ± 0.2%
Measuring range (Flow rate): 0.01m/s～15m/s

Vortex flowmeter is mainly used for the flow measurement of industrial pipeline medium fluids, such as gas, liquid, steam and other media. It is characterized by small pressure loss, large range, high accuracy, and is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring volume flow under working conditions. There are no moving mechanical parts, so the reliability is high, the maintenance is small, and the instrument parameters can be stable for a long time.

Gas turbine flowmeter has high measurement accuracy and stable performance, so it can be seen in many applications with high configuration requirements. Today, the flowmeter manufacturer Qingtian Instrument Xiaobian mainly to talk with you about some problems encountered in the application process of gas turbine flowmeter and the corresponding treatment methods.

Liquid turbine flow meters are devices used to measure the flow of liquids through a pipeline. They operate on the principle of a turbine rotor turning in response to fluid flow. Here are some advantages of liquid turbine flow meters:

Nominal diameter: DN50-DN400
Functional application: Mainly used for trade settlement, mobile prepaid system, remote meter reading
Advantages and characteristics: Low starting flow, good repeatability, small pressure loss
Applicable medium: Natural gas, compressed air, nitrogen, etc

Nominal diameter: DN25～DN300mm
Accuracy: liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Material: 304, 316L various materials
Measuring media： Steam, compressed air, liquid (single phase media)
LUGB flange clamped vortex street steam flowmeter is a commonly used structure, its body itself does not have a connection flange, in connection with the pipe, the flowmeter clamped between two special flanges, and then bolted.

electromagnetic flowmeters are employed in HVAC (heating, ventilation, and air conditioning) systems to measure the flow of water or other fluids used for temperature control. The precision and reliability of these flowmeters ensure optimal performance of HVAC systems, leading to energy savings and improved comfort in various buildings and facilities.

Medium Temperature: -20~+60 degC(Integral type)
Remote type ( Neoprene ,Hard Rubber ,Polyurethane ,EPDM) -10~+80degC
Remote type(PTFE/PFA/FEP) -10~+160degC
Ambient Temperature: -20~+60deg C
Ambient Humidity: 5-100%RH(relative humidity)
Measuring Range： Max 15m/s
Conductivity： >5us/cm
Protection Class： IP65(Standard); IP68(Optional for remote type)
Process Connection： Flange (Standard), Wafer, Thread, Tri-clamp etc (Optional)
Output Signal： 4-20mA/Pulse
Communication： RS485(Standard), HART(Optional),GPRS/GSM (Optional)
Power Supply： AC220V (can be used for AC85-250V)
DC24V (can be used for DC20-36V)
DC12V (optional), Battery Powered 3.6V (optional)

Turbine flow meters are used to measure clean, dry gases and liquids such as hydrocarbons, chemicals, gases and vapors, fuels and other types of liquids with lower viscosity, and for applications requiring highly accurate and precise measurements.

Electromagnetic water meters offer several advantages in water measurement applications, particularly in industrial and municipal settings. Here are some key advantages of electromagnetic water meters:

The smart precession vortex flowmeter consists of the following seven basic components:
1. Vortex generator,2. Shell,3. Intelligent flowmeter integrator, 4. Temperature sensor,5. Pressure sensor,6. Piezoelectric crystal sensor,7.Disrotator

Vortex flowmeters are not only suitable for measuring a variety of low viscosity liquids, but also mainly for industrial measurement of gases and vapors. When measuring the volume flow of gas, vortex flowmeters are not affected by changes in fluid temperature, pressure, density, viscosity and other properties, so the measurement is very accurate and is the first choice for measuring air.

Liquid turbine flowmeters also find application in the pharmaceutical industry, where precise measurements of liquid flow rates are vital for the production of pharmaceutical products. From monitoring the flow of ingredients during manufacturing to ensuring accurate dosing in pharmaceutical research and development, these flowmeters contribute to the quality and consistency of pharmaceutical processes.

Connection mode：Thread, clamp, flange, clamp type
Accuracy：±1%R、±0.5%R、±0.2%R (to be customized)
Sensor material：304, 316 stainless steel, etc
Use conditions： Medium temperature：-20℃～+120℃  Ambient temperature：-20℃～+60℃
Relative humidity：5%-90%         Atmospheric pressure：86Kpa～106Kpa
Signal output function：Pulse signal, 4-20mA signal
Communication output function：RS485 communication, HART protocol, etc
Working power supply：External power supply: 24VDC±15%, ripple ≤±5%, suitable for 4-20mA output, pulse output, RS485, etc
Internal power supply: 1 set of 3.6V10AH lithium battery, the battery voltage can work normally at 2.0-3.0V
Signal line interface：Basic model: Hausmann connector or three-core cable; Explosion-proof type, internal thread M20*1.5
Explosion-proof class：Exia II CT or Exd II BT6
Protection class：IP65 or higher customizable

Pipe Size: DN25-DN1200mm (1”~48”)
Fluid: Single medium liquid
Temperature: -40℃~80℃ (standard), -40℃~130℃ (optional)
Accuracy: ±1% of measured value
Flow Range: ±0.01 m/s~ ±12 m/s
