1.0% Accuracy Intelligent Precession Vortex Flowmeter Nitrogen Gas Flowmeter Industrial Metering Meter

The robust and durable construction of vortex flow meters contributes to their popularity in industrial settings. With no moving parts in direct contact with the fluid, these meters offer minimal maintenance requirements and extended operational life. Moreover, advancements in technology have allowed for the development of digital vortex flow meters that offer enhanced precision and communication capabilities, facilitating integration with modern process control systems.

Measuring medium：Liquid, gas, saturated steam, superheated steam
Accuracy：Liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Working pressure：1.6MPa，2.5MPa，4.0MPa，6.4MPa
Medium temperature：Ordinary type -40 ~ 150℃
Medium temperature type -40 ~ 250℃
High temperature type -40 ~ 350℃
Output signal：Three-wire voltage pulse, low level 0 ~ 1V,
high level > 4V, duty cycle 50%;
Two-wire system standard current 4 ~ 20mA;
Three-wire system standard current 0 ~ 10mA
Working environment：-35℃～+60℃，Humidity ≤95%RH
Working power supply：DC12V；DC24V
Material：Carbon steel, stainless steel
Explosion-proof type：Intrinsically safe ExibIICT6

Precautions for installation and use of vortex flow meter

In HVAC (heating, ventilation, and air conditioning) systems, vortex flow meters are utilized to measure the flow rates of air and other gases. Their ability to provide accurate readings in a wide range of temperatures and pressures ensures efficient HVAC system operation. Vortex flow meters contribute to energy savings by enabling precise control of airflow and facilitating better management of heating and cooling processes.

Across various industries, including pharmaceuticals, food and beverage, and power generation, vortex flow meters continue to find applications in processes requiring precise fluid flow measurement. Their adaptability to different fluid types, low maintenance requirements, and reliable performance make them indispensable tools for optimizing industrial processes and ensuring the accurate allocation of resources.

Vortex flowmeter is mainly used to set up a vortex generating body (resistance fluid) in the fluid, from both sides of the vortex generating body alternately to produce regular vortices, to measure the flow of fluid, vortex flowmeter is mainly used for industrial pipeline fluid flow measurement, such as gas, liquid, steam and other media. It is characterized by small pressure loss, large range, high accuracy, and is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring volume flow under working conditions. In daily use, the output signal may be unstable, causing this phenomenon to be excluded from the following points:

Vortex flow meters offer a host of advantages that make them a preferred choice in various industrial applications. One key advantage is their versatility in measuring the flow of liquids, gases, and steam. Unlike some other flow measurement technologies, vortex flow meters can handle a wide range of fluids, making them suitable for diverse industries such as oil and gas, water treatment, chemical processing, and HVAC systems.

Measured Medium: Liquid, Gas, Steam
Medium Temp: -40℃~+200℃; -40℃~+280℃; 40℃~+350℃
Nominal Pressure: 1.6MPa;2.5MPa;4.0MPa;6.4MPa(Other pressure can be custom,need consult supplier)
Accuracy: 1.0%(Flange), 1.5%(Insertion)
Material: SS304(Standard), SS316(Optional)

Vortex flowmeter can be widely used in large, medium and small kinds of pipeline water supply and drainage, industrial circulation, sewage treatment, oil and chemical reagents and compressed air, saturated and superheated steam, natural gas and various media flow measurement and can be used as a flow transmitter in automatic control system, long service life. Points of attention for vortex flowmeter installation:

As industries continue to seek efficient and reliable flow measurement solutions, vortex flow meters stand out for their accuracy, adaptability, and durability. Their ability to provide real-time data and facilitate process optimization makes them indispensable tools for ensuring the efficient operation of various industrial processes where precise flow measurements are essential.

Measuring medium：Liquid, gas, saturated steam, superheated steam
Accuracy：Liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Working pressure：1.6MPa，2.5MPa，4.0MPa，6.4MPa
Medium temperature：Ordinary type -40 ~ 150℃
Medium temperature type -40 ~ 250℃
High temperature type -40 ~ 350℃
Output signal：Three-wire voltage pulse, low level 0 ~ 1V,
high level > 4V, duty cycle 50%;
Two-wire system standard current 4 ~ 20mA;
Three-wire system standard current 0 ~ 10mA
Working environment：-35℃～+60℃，Humidity ≤95%RH
Working power supply：DC12V；DC24V
Material：Carbon steel, stainless steel
Explosion-proof type：Intrinsically safe ExibIICT6

In chemical processing plants, vortex flow meters play a crucial role in measuring the flow of corrosive or abrasive liquids. Their resistance to harsh chemical environments, combined with their ability to offer accurate readings even in challenging conditions, makes them valuable assets for ensuring the efficiency and safety of chemical processes. The meters’ capability to handle different fluid types and maintain accuracy contributes to their widespread adoption in chemical industries.

Vortex flowmeter is one of the commonly used instruments in daily production, therefore, failure will occur from time to time, the main reasons for the inaccurate flow accuracy of the vortex include: the influence of temperature on the measurement, the influence of the accumulation of the vortex generating body on the flow surface, the influence caused by the inconsistency between the distribution tube and the inner flow meter.

Vortex flowmeter is mainly used for the flow measurement of industrial pipeline medium fluids, such as gas, liquid, steam and other media. It is characterized by small pressure loss, large range, high accuracy, and is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring volume flow under working conditions. There are no moving mechanical parts, so the reliability is high, the maintenance is small, and the instrument parameters can be stable for a long time.

Vortex flowmeter is a new type flowmeter for measuring fluid flow in closed pipeline according to Karman vortex principle. It is mainly used for the flow measurement of industrial pipeline medium fluids, such as gas, liquid, vapor and other media. It is characterized by small pressure loss, large range, high accuracy, and is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring volume flow under working conditions.

Nominal diameter: DN25～DN300mm
Accuracy: liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Material: 304, 316L various materials
Measuring media： Steam, compressed air, liquid (single phase media)

Temperature and pressure compensation integrated vortex flowmeter performance advantages:

When the vortex flowmeter has no liquid flow in the pipeline, the receiver counts abnormally due to the noise generated by the pipeline vibration, and the sensitivity of the instrument should be adjusted.

Nominal diameter: DN15～DN300mm
Accuracy: liquid ±1.0%, gas (steam) ±1.5%, plug-in ±2.5%
Structure form: Integrated, split, temperature and pressure compensation
Applicable medium: liquid, gas, saturated steam, superheated steam

Vortex flowmeter is widely used because of its wide range, small pressure loss, medium accuracy, linear output, no moving parts, high reliability, small maintenance, medium low price, relatively high performance and price characteristics.

Intelligent vortex flowmeters can measure air. Vortex flowmeter is a new flowmeter for flow measurement based on Karman vortex principle. It has good medium adaptability and can directly measure the volume flow of various media (including air). When measuring air, the vortex flowmeter generates regular vortices through the triangular column vortex generator set in the fluid, and the frequency of these vortices is proportional to the average velocity of the measured medium, so that the air flow can be calculated.
